NDS1/2 client status structure. More...
#include <daqc.h>
Public Attributes | |
| enum nds_version | nds_versn |
| NDS server type. | |
| uint4_type | num_chan_request |
| uint4_type | num_chan_alloc |
| chan_req_t * | chan_req_list |
| int | blocks |
| daq_block_t * | tb |
| size_t | tb_size |
| struct signal_conv1 * | s |
| int | s_size |
| int | nds1_ver |
| int | nds1_rev |
| void * | auth_ctx |
| int | err_num |
| struct daq_private_ * | conceal |
Detailed Description
NDS1/2 client status structure.
The daq_t structure contains all the status and control information for the NDS client. It is used by each of the daq_access functions.
Member Data Documentation
◆ auth_ctx
| void* daq_::auth_ctx |
authentication context
◆ blocks
| int daq_::blocks |
Block count??? zero for on-line transmission; positive for off-line
◆ chan_req_list
| chan_req_t* daq_::chan_req_list |
Channel request list.
◆ conceal
| struct daq_private_* daq_::conceal |
Handle to internal data
◆ err_num
| int daq_::err_num |
Alternate error number.
◆ nds1_rev
| int daq_::nds1_rev |
NDS1 server protocol revision received by NDS1 'revision' command
◆ nds1_ver
| int daq_::nds1_ver |
NDS1 server protocol version received by NDS1 'version' command
◆ nds_versn
| enum nds_version daq_::nds_versn |
◆ num_chan_alloc
| uint4_type daq_::num_chan_alloc |
Number of channels request structures allocated.
◆ num_chan_request
| uint4_type daq_::num_chan_request |
Number of channels requested.
◆ s
| struct signal_conv1* daq_::s |
signal conversion data; dynamically allocated and reallocated as needed; freed in daq_recv_shutdown()
◆ s_size
| int daq_::s_size |
size of the above malloced data in elements (sizeof(signal_conv_t1) each)
◆ tb
| daq_block_t* daq_::tb |
transmission block; dynamically allocated and reallocated as needed; freed in daq_recv_shutdown()
◆ tb_size
| size_t daq_::tb_size |
size of the above malloced data
The documentation for this struct was generated from the following file:
- src/client/daqc.h
